Specifications

Environmental
Operating Temperature: 32° to 122° F (0° to 50° C)
Storage Temperature: 4° to 158° F (-20° to 70° C)
Humidity: 5 to 95% (non-condensing)
Power Consumption
AC Input: 100-240 V AC ±10%, 50/60 Hz, 1-0.5A
Dimensions
1-Slot: 1.55"H x 4.75"L x 7.31"D (3.94 cm H x 12.07 cm L x 18.57 cm D)
2-Slot: 2.30"H x 4.75"L x 7.31"D (5.84 cm H x 12.07 cm L x 18.57 cm D)
Heat Generation
51 BTU/hr. maximum

Electrostatic Discharge Precautions

Electrostatic discharge (ESD) can cause damage to any product, add-in modules or stand alone
units, containing electronic components. Always observe the following precautions when
installing or handling these kinds of products
1. Do not remove unit from its protective packaging until ready to install.
2. Wear an ESD wrist grounding strap before handling any module or component. If the
wrist strap is not available, maintain grounded contact with the system unit throughout
any procedure requiring ESD protection.
3. Hold the units by the edges; do not touch the electronic components or gold connectors.
4. After removal, always place the boards on a grounded, static-free surface, ESD pad or in a
proper ESD bag. Do not slide the modules or stand alone units over any surface.
WARNING! Integrated circuits and fiber optic components are
extremely susceptible to electrostatic discharge damage. Do not
handle these components directly unless you are a qualified service
technician and use tools and techniques that conform to accepted
industry practices.

IMC Networks Technical Support

Tel: (949) 465-3000 or (800) 624-1070 (in the U.S. and Canada);
+32-16-550880 (Europe)
Fax: (949) 465-3020
E-Mail: techsupport@imcnetworks.com
Web: www.imcnetworks.com
