Technical Specifications; Ordering Information - IMC Networks iMcV-T1 Specification

Technical Specifications

• Protocol-Selectable — Operates at T1/J1 (1.544) and E1 (2.048) protocols
• Includes ability to manage remote unit
• Conduct three types of loopback tests
• Full bit rate for customer traffic
• EGL, Transmit Data Source, Line Encoding and NRZ
• Includes DTE/DCE switch on converter
• Features LinkLoss and FiberAlert
• Installs in any iMediaChassis serues or MediaChassis series
• Supports GUI-Based iView²
• 50/125µm or 62.5/125µm multi-mode fiber
• 9/125µm single-mode fiber
• Available for single-strand fiber
• Connectors: RJ-48 and ST or SC
• Includes diagnostic LEDs
• Includes hot-swappable architecture
Fiber Optics Specifications
For each product listed below in the Ordering Information section, the DISTANCE represents an approximate fiber distance based on industry-standard
fiber attenuation specifications. Actual distances will vary for each installation. For complete power budgets and information on calculating specific
distances, visit www.imcnetworks.com/go/fcs or contact IMC Networks Fiber Consulting Services at 949-465-3000.

Ordering Information

Always deploy iMcV-T1/E1/J1 converters in pairs.
PART NUMBER DEScRIPTION
iMcV-T1/E1/J1 Module
850-14198 iMcV-T1/E1/J1,TP/Fiber-MM850-ST
850-14199 iMcV-T1/E1/J1,TP/Fiber-MM850-SC
850-14200 iMcV-T1/E1/J1, TP/Fiber-MM1300-ST
850-14201 iMcV-T1/E1/J1, TP/Fiber-MM1300-SC
850-14202 iMcV-T1/E1/J1, TP/Fiber-SM1310/PLUS-ST
850-14203 iMcV-T1/E1/J1, TP/Fiber-SM1310/PLUS-SC
850-14204 iMcV-T1/E1/J1, TP/Fiber-SM1310/LONG-ST
850-14205 iMcV-T1/E1/J1, TP/Fiber-SM1310/LONG-SC
850-14206 iMcV-T1/E1/J1, TP/Fiber-SM1550/LONG-SC
iMcV-T1/E1/J1 Single-Strand Fiber Module*
850-14288 iMcV-T1/E1/J1, TP/SSFiber, MM1310-SC
850-14289 iMcV-T1/E1/J1, TP/SSFiber, MM1550-SC
850-14290 iMcV-T1/E1/J1, TP/SSFiber-SM1310-SC
850-14291 iMcV-T1/E1/J1, TP/SSFiber-SM1550-SC
850-14292 iMcV-T1/E1/J1, TP/SSFiber-SM1310/PLUS-SC
850-14293 iMcV-T1/E1/J1, TP/SSFiber-SM1550/PLUS-SC
850-14294 iMcV-T1/E1/J1, TP/SSFiber-SM1310/LONG-SC
850-14295 iMcV-T1/E1/J1, TP/SSFiber-SM1550/LONG-SC
* These products have single-strand fiber technology.
For more information go to: www.imcnetworks.com/products/SSFX.cfm
IMC Networks
Headquarters
19772 Pauling
Foothill Ranch, CA 92610
TEL: 949-465-3000
FAX: 949-465-3020
sales@imcnetworks.com
DISTANcE
2 km
2 km
5 km
5 km
40 km
40 km
80 km
80 km
80 km
2 km
2 km
20 km
20 km
40 km
40 km
60 km
60 km
IMC Networks IMC Networks
Europe Eastern US/Latin America
Herseltsesteenweg 268
28050 U.S. Hwy. 19 North, Suite 306
B-3200 Aarschot, Belgium Clearwater, FL 33761
TEL: +32-16-550880 TEL: 727-797-0300
FAX: +32-16-550888 FAX: 727-797-0331
eurosales@imcnetworks.com latinsales@imcnetworks.com
Regulatory Approvals:
• FCC Class A
• UL/cUL
• CSA
• CE
Shipping Weight:
0.30 lbs (.11 kg)
Operating Temperature:
+32° to +122° F (0° to +50° C); 5% to 95% (non-condensing), 0 – 10,000 ft. altitude
Storage Temperature:
-13° to +158° F (-25° to +70° C); 5% to 95% (non-condensing)
PART NUMBER DEScRIPTION
iMcV-T1/E1/J1 cWDM Fiber Module
850-14271 iMcV-T1/E1/J1, TP/Fiber-CWDM-SM1310-SC
850-14272 iMcV-T1/E1/J1, TP/Fiber-CWDM-SM1330-SC
850-14273 iMcV-T1/E1/J1, TP/Fiber-CWDM-SM1350-SC
850-14277 iMcV-T1/E1/J1, TP/Fiber-CWDM-SM1370-SC
850-14278 iMcV-T1/E1/J1, TP/Fiber-CWDM-SM1390-SC
850-14279 iMcV-T1/E1/J1, TP/Fiber-CWDM-SM1410-SC
850-14281 iMcV-T1/E1/J1, TP/Fiber-CWDM-SM1430-SC
850-14283 iMcV-T1/E1/J1, TP/Fiber-CWDM-SM1450-SC
850-14284 iMcV-T1/E1/J1, TP/Fiber-CWDM-SM1470-SC
850-14285 iMcV-T1/E1/J1, TP/Fiber-CWDM-SM1490-SC
850-14286 iMcV-T1/E1/J1, TP/Fiber-CWDM-SM1510-SC
850-14287 iMcV-T1/E1/J1, TP/Fiber-CWDM-SM1530-SC
850-14296 iMcV-T1/E1/J1, TP/Fiber-CWDM-SM1550-SC
850-14297 iMcV-T1/E1/J1, TP/Fiber-CWDM-SM1570-SC
850-14298 iMcV-T1/E1/J1, TP/Fiber-CWDM-SM1590-SC
850-14299 iMcV-T1/E1/J1, TP/Fiber-CWDM-SM1610-SC
IMC Networks
Fiber Consulting Services
For information call:
TEL: 949-465-3000
1-800-624-1070
+32-16-550880
(Europe)
fcs@imcnetworks.com
Copyright © 2010 IMC Networks.
reserved. The information in this document is
subject to change without notice. IMC Networks
assumes no responsibility for any errors that may
appear in this document. Specific product names
may be trademarks or registered trademarks and
(US/CAN)
are the property of their respective companies.
DS-iMcV-T1E1-1010
DISTANcE
80 km
80 km
80 km
80 km
80 km
80 km
80 km
80 km
80 km
80 km
80 km
80 km
80 km
80 km
80 km
80 km
