Table 19
Supplementary Services Parameters
Parameter
Enable Caller ID
[EnableCallerID]
Caller ID Type
[CallerIDType]
MWI Parameters
Enable MWI
[EnableMWI]
MWI Analog Lamp
[MWIAnalogLamp]
MWI Display
[MWIDisplay]
Subscribe to MWI
[EnableMWISubscription]
MWI Server IP Address
[MWIServerIP]
MWI Subscribe Expiration
Time
[MWIExpirationTime]
MWI Subscribe Retry Time
[SubscribeRetryTime]
3Com VCX V7111 VoIP SIP Gateway User Manual
Description
No [0] = Disable the Caller ID service (default).
Yes [1] = Enable the Caller ID service.
If the Caller ID service is enabled, then, for FXS gateways, calling number and Display
text are sent to gateway port.
For FXO gateways, the Caller ID signal is detected and is sent to IP in SIP INVITE
message (as "Display" element).
For information on the Caller ID table see
To disable/enable caller I generation per port, see
Defines one of the following standards for detection (FXO) and generation (FXS) of Caller
ID signals.
Bellcore [0] (default)
ETSI [1]
NTT [2]
DTMF ETSI [16]
Denmark [17]
India [18]
Note: The Caller ID signals are generated/detected between the first and the second
rings.
Enable MWI (message waiting indication).
Disable [0] = Disabled (default).
Enable [1] = MWI service is enabled.
This parameter is applicable only to FXS gateways.
Note: The VCX V7111 only supports reception of MWI.
For detailed information on MWI, see
Disable [0] = Disable (default).
Enable [1] = Enable visual Message Waiting Indication, supplies line voltage of
approximately 100 VDC to activate the phone's lamp.
This parameter is applicable only to FXS gateways.
Disable [0] = MWI information isn't sent to display (default).
Enable [1] = MWI information is sent to display.
If enabled, the gateway generates an MWI FSK message that is displayed on the MWI
display.
This parameter is applicable only to FXS gateways.
Disable [0] = Disable MWI subscription (default).
Enable [1] = Enable subscription to MWI (to MWIServerIP address).
MWI server IP address. If provided, the gateway subscribes to this IP address.
Can be configured as a numerical IP address or as a domain name. If not configured, the
Proxy IP address is used instead.
MWI subscription expiration time in seconds.
The default is 7200 seconds. The range is 10 to 72000.
Subscription retry time in seconds.
The default is 120 seconds. The range is 10 to 7200.
Caller ID on page 102.
Caller ID Permissions
Message Waiting Indication
on page 104.
on page 164.
