The new logo appears on all Web Interface screens.
If you encounter any problem during the loading of the files, or you want to restore the default
images, click the Restore Default Images button.
To replace 3Com's default logo with your own corporate image via the ini file, follow these
steps:
1
Place your corporate logo image file in the same folder as where the device's ini file is
located (i.e., the same location defined in the BootP/TFTP configuration utility). For
detailed information on the BootP/TFTP, see
Configuration Utility
2
Add/modify the two ini file parameters in
in Modifying an ini File
Note that loading the device's ini file via the 'Configuration File' screen in the Web Interface
doesn't load the corporate logo image files as well.
Table 62
Customizable Logo ini File Parameters
Parameter Description
LogoFileName The name of the image file containing your corporate logo.
Use a gif, jpg or jpeg image file.
The default is 3Com's logo file.
Note: The length of the name of the image file is limited to 47 characters.
LogoWidth Width (in pixels) of the logo image.
Note: The optimal setting depends on the resolution settings.
The default value is 339, which is the width of 3Com's displayed logo.

Replacing the Main Corporate Logo with a Text String

The main corporate logo can be replaced with a text string.
To replace 3Com's default logo with a text string via the Web Interface, modify the two ini
file parameters in Table 63
Parameters via the Web Interface's AdminPage
To replace 3Com's default logo with a text string via the ini file, add/modify the two ini file
parameters in Table 63
page 147.
Table 63
Web Appearance Customizable ini File Parameters
Parameter Description
0 = Logo image is used (default).
UseWebLogo
1 = Text string is used instead of a logo image.
WebLogoText Text string that replaces the logo image.
The string can be up to 15 characters.
3Com VCX V7111 VoIP SIP Gateway User Manual
on page 209.
Table 62
on page 147.
according to the procedure described in
according to the procedure described in
Appendix B: The BootP/TFTP
according to the procedure described
on page 233.
Modifying an ini File
Modifying ini File
on
231
