5
Click the Submit button to save your changes.
6 To save the changes so they are available after a power fail see
page 145.
Table 35 Caller ID ini File Parameter
Parameter Name in ini File
CallerDisplayInfoX
Call Forward
The VoIP gateway allows you to forward incoming IP Tel calls (using 302 response) based
on the VoIP gateway port to which the call is routed (applicable only to FXS gateways).
The Call Forwarding Table is applicable only if the Call Forward feature is enabled. To
enable Call Forward set 'Enable Call Forward' to 'Enable' in the 'Supplementary Services'
screen, or 'EnableForward=1' in the ini file (see
To configure the Call Forward table, follow these steps:
1 Open the 'Call Forward Table' screen (Protocol Management menu > Endpoint
Settings submenu > Call Forward option); the 'Call Forward Table' screen is displayed.
Figure 46
Call Forwarding Table Screen
2
Configure the Call Forward parameters for each port according to the table below.
3 Click the Submit button to save your changes.
4
To save the changes so they are available after a power fail see
page 145.
3Com VCX V7111 VoIP SIP Gateway User Manual
Parameter Format
CallerDisplayInfo<channel> = <Caller ID string>,<Restriction>
0 = Not restricted (default).
1 = Restricted.
For example:
CallerDisplayInfo0 = Susan C.,0
CallerDisplayInfo2 = Mark M.,1
Note 1: The numbering of channels starts with 0.
Note 2: This parameter can appear up to eight times for 8FXS, and up to
24 times for 24FXS.
Table 19 on page 69).
Save Configuration on
Save Configuration on
