For a continuous tone (such as dial tone), only the "First Signal On time" should be specified.
In this case, the parameter specifies the detection period. For example, if it equals 300, the
tone is detected after 3 seconds (300 x 10 msec). The minimum detection time is 100 msec.
Users can specify several tones of the same type. These additional tones are used only for
tone detection. Generation of a specific tone conforms to the first definition of the specific
tone. For example, Users can define an additional dial tone by appending the second dial
tone's definition lines to the first tone definition in the ini file. The VCX V7111 reports dial
tone detection if either of the two tones is detected.
The Call Progress Tones section of the ini file comprises the following segments:
[NUMBER OF CALL PROGRESS TONES] – Contains the following key:
"Number of Call Progress Tones" defining the number of Call Progress Tones that are
defined in the file.
[CALL PROGRESS TONE #X] – containing the Xth tone definition (starting from 1 and
not exceeding the number of Call Progress Tones defined in the first section) using the
following keys:
Tone Type – Call Progress Tone type
Figure 76
Call Progress Tone Types
- Dial Tone
1
2 - Ringback Tone
3 - Busy Tone
7 - Reorder Tone
8 - Confirmation Tone
9 - Call Waiting Tone
15 - Stutter Dial Tone
16 - Off Hook Warning Tone
17 - Call Waiting Ringback Tone
23 - Hold Tone
Low Freq [Hz] – Frequency in hertz of the lower tone component in case of dual
frequency tone, or the frequency of the tone in case of single tone.
High Freq [Hz] – Frequency in hertz of the higher tone component in case of dual
frequency tone, or zero (0) in case of single tone.
Low Freq Level [-dBm] – Generation level 0 dBm to –31 dBm in [dBm].
High Freq Level – Generation level. 0 to –31 dBm. The value should be set to '32' in
the case of a single tone.
First Signal On Time [10 msec] – "Signal On" period (in 10 msec units) for the first
cadence on-off cycle.
First Signal Off Time [10 msec] – "Signal Off" period (in 10 msec units) for the first
cadence on-off cycle.
Second Signal On Time [10 msec] – "Signal On" period (in 10 msec units) for the
second cadence on-off cycle.
Second Signal Off Time [10 msec] – "Signal Off" period (in 10 msec units) for the
second cadence on-off cycle.
