Table 14
Protocol Definition, General Parameters
Parameter
Asserted Identity Mode
[AssertedIdMode]
Enable T.38 Fax Relay
[IsFaxUsed]
Detect Fax on Answer Tone
[DetFaxOnAnswerTone]
SIP Local Port
[LocalSIPPort]
SIP Destination Port
[SIPDestinationPort]
Use "user=phone" in SIP URL
[IsUserPhone]
Use "user=phone" in From
header
[IsUserPhoneInFrom]
Tel to IP No Answer Timeout
[IPAlertTimeout]
Add Number Plan and Type to
Remote Party ID Header
[AddTON2RPI]
Use Source Number as Display
Name
[UseSourceNumberAsDispla
yName]
3Com VCX V7111 VoIP SIP Gateway User Manual
Description
Disable [0] = None (default).
Adding PAsserted Identity [1].
Adding PPrefered Identity [2].
The Asserted ID mode defines the header that is used in the generated INVITE request.
The header also depends on the calling Privacy: allowed or restricted.
The P-asserted (or P-preferred) headers are used to present the originating party's Caller
ID. The Caller ID is composed of a Calling Number and (optionally) a Calling Name.
P-asserted (or P-preferred) headers are used together with the Privacy header. If Caller
ID is restricted the "Privacy: id" is included. Otherwise for allowed Caller ID the "Privacy:
none" is used. If Caller ID is restricted (received from Tel or configured in the gateway),
the From header is set to <anonymous@anonymous.invalid>.
No [0] = T.38 Fax relay is disabled (default).
Yes [1] = Enable T.38 Fax Relay.
Note: If enabled, the parameter 'Fax Transport Mode' is automatically set to 1 (T.38
relay).
Initiate T.38 on Preamble
receiving of HDLC preamble signal from Fax (default)
Initiate T.38 on CED [1] = Terminating fax gateway initiates T.38 session on
receiving of CED answer tone from Fax.
Note: This parameters is applicable only if 'IsFaxUsed = 1'.
Local UDP port used to receive SIP messages.
The default value is 5060.
SIP UDP destination port for sending SIP messages.
The default value is 5060.
No [0] = "user=phone" string isn't used in SIP URL.
Yes [1] = "user=phone" string is part of the SIP URL (default).
No [0] = Doesn't use ";user=phone" string in From header (default).
Yes [1] = ";user=phone" string is part of the From header.
Defines the time (in seconds) the gateway waits for a 200 OK response from the called
party (IP side) after sending an Invite message. If the timer expires, the call is released.
The valid range is 0 to 3600. The default value is 180.
No [0] = TON/PLAN parameters aren't included in the RPID header.
Yes [1] = TON/PLAN parameters are included in the RPID header (default).
If RPID header is enabled (EnableRPIHeader = 1) and 'AddTON2RPI=1', it is possible to
configure the calling and called number type and number plan using the Number
Manipulation tables for Tel IP calls.
No [0] = Interworks the Tel calling name to SIP Display Name (default).
Yes [1] = Set Display Name to Calling Number if not configured.
Applicable to Tel IP calls. If enabled and calling party name is not defined
(CallerDisplayInfoX = <name> is not specified per gateway's x port), the calling number is
used instead.
[0] = Terminating fax gateway initiates T.38 session on
