C 5: C
HAPTER
V7111

Configuration Concepts

Customers can use the VCX V7111 in a wide variety of applications, enabled by its
parameters and configuration files (e.g., Call Progress Tones (CPT), etc.). The parameters
can be configured and configuration files can be loaded using:
A standard Web Browser (described and explained in this section).
A configuration file referred to as the ini file. For information on how to use the ini file see
Chapter 6: ini File Configuration of the VCX V7111
An SNMP browser software (see
3Com's Element Management System (EMS) (see
System on page 201
To upgrade the VCX V7111 (load new software or configuration files onto the gateway) use
the Software Upgrade wizard, available through the Web Interface (see
Wizard on page 137), or alternatively use the BootP/TFTP configuration utility (see
Upgrading The VCX V7111
For information on the configuration files see
V7111 on page 147.

Overview of the Embedded Web Server

The Embedded Web Server is used both for gateway configuration, including loading of
configuration files, and for run-time monitoring. The Embedded Web Server can be accessed
from a standard Web browser, such as Microsoft™ Internet Explorer, Netscape™ Navigator,
etc. Specifically, Users can employ this facility to set up the gateway configuration
parameters. Users also have the option to remotely reset the gateway and to permanently
apply the new set of parameters.

Computer Requirements

To use the Web Interface, the following is needed:
A computer capable of running your Web browser.
A network connection to the VoIP gateway.
One of the following compatible Web browsers:
Microsoft Internet Explorer (version 6.0 and higher).
Netscape Navigator (version 7.0 and higher).
Some Java-script applications are not supported in Netscape.
3Com VCX V7111 VoIP SIP Gateway User Manual
ONFIGURING THE
Chapter 11: SNMP-Based Management
and to 3Com's EMS user manual or EMS product description).
on page 186).
Chapter 6: ini File Configuration of the VCX
VCX
on page 147.
3Com's Element Management
Software Upgrade
on page 189).
