3
In the 'Tel to IP Reasons' table, from the drop-down list select up to 4 different call failure
reasons that invoke an alternative Tel to IP routing.
4
Click the Submit button to save your changes.
5 To save the changes so they are available after a power fail see
page 145.
Table 27
Reasons for Alternative Routing ini File Parameter
Parameter Name in ini File
AltRouteCauseTel2IP
AltRouteCauseIP2Tel

Configuring the Profile Definitions

Utilizing the Profiles feature, the VCX V7111 provides high-level adaptation when connected
to a variety of equipment (from both Tel and IP sides) and protocols, each of which require a
different system behavior. Using Profiles, users can assign different Profiles (behavior) on a
per-call basis, using the Tel to IP and IP to Hunt Group Routing tables, or associate different
Profiles to the gateway's endpoint(s). The Profiles contain parameters such as Coders, T.38
Relay, Voice and DTMF Gains, Silence Suppression, Echo Canceler, RTP DiffServ, Current
Disconnect and more. The Profiles feature allows users to tune these parameters or turn
them on or off, per source or destination routing and/or the specific gateway or its ports. For
example, specific ports can be designated to have a profile which always uses G.711.
Each call can be associated with one or two Profiles, Tel Profile and (or) IP Profile. If both IP
and Tel profiles apply to the same call, the coders and other common parameters of the
preferred Profile (determined by the Preference option) are applied to that call. If the
Preference of the Tel and IP Profiles is identical, the Tel Profile parameters are applied.
The default values of the parameters in the Tel and IP Profiles are identical to the
Web/ini file parameter values. If a value of a parameter is changed in the Web/ini
file, it is automatically updated in the Profiles correspondingly. After any
parameter in the Profile is modified by the user, modifications to parameters in
the Web/ini file no longer impact that Profile.
Coder Group Settings
Use the Coders Group Settings screen to define up to four different coder groups. These
coder groups are used in the Tel and IP Profile Settings screens to assign different coders to
Profiles.
3Com VCX V7111 VoIP SIP Gateway User Manual
Parameter Format
AltRouteCauseTel2IP = <SIP Call failure reason from IP>
For example:
AltRouteCauseTel2IP = 408 (Response timeout).
AltRouteCauseTel2IP = 486 (User is busy).
Note: This parameter can appear up to 4 times.
AltRouteCauseIP2Tel = <Call failure reason from Tel>
For example:
AltRouteCauseIP2Tel = 3
AltRouteCauseIP2Tel = 17 (Busy here).
Note: This parameter can appear up to 4 times.
Save Configuration
(No route to destination).
on
89
