Figure 47 VCX V7111 FXS Caller ID Permission Screen
2 In the 'Caller ID' field, select one of the following:
Enable – Enables Caller ID generation (FXS) or detection (FXO) for the specific port.
Disable – Caller ID generation (FXS) or detection (FXO) for the specific port is
disabled.
Empty – Caller ID generation (FXS) or detection (FXO) for the specific port is
determined according to the parameter 'EnableCallerID' (see
3
Repeat step 2 for each port.
4 Click the Submit button to save your changes.
5
To save the changes so they are available after a power fail see
page 145.
Table 37
Authentication ini File Parameter
Parameter Name in ini File
EnableCallerID_X

Configuring the FXO Parameters

Use this screen to configure the gateway's specific FXO parameters.
To configure the FXO parameters, follow these steps:
1
Open the 'FXO Settings' screen (Protocol Management menu > FXO); the 'FXO
Settings' screen is displayed.
3Com VCX V7111 VoIP SIP Gateway User Manual
Parameter Format
EnableCallerID_<Port> = <Caller ID>
Caller ID:
0 = Disabled (default).
1 = Enabled.
If not configured, use the global parameter 'EnableCallerID'.
Note 1: The numbering of ports starts with 0.
Note 2: This parameter can appear up to eight times for 8FXS and up to 24
times for 24FXS.
Table 19 on page 69).
Save Configuration on
105
