Supporting Soundpoint Ip 300 And 500 Phones - Polycom SIP 2.2.0 Administrator's Manual

Administrator's Guide SoundPoint IP / SoundStation IP
Warning

Supporting SoundPoint IP 300 and 500 Phones

3 - 18
2. Customize new configuration files or apply new or changed parameters
to the old configuration files.
Differences between old and new versions of configuration files are
explained in the Release Notes that accompany the software. Both
mandatory and optional changes may present. Changes to site-wide
configuration files such as sip.cfg can be done manually, but a scripting
tool is useful to change per-phone configuration files.
The configuration files listed in CONFIG_FILES attribute of the master configuration
file must be updated when the software is updated. Any new configuration files
must be added to the CONFIG_FILES attribute in the appropriate order.
Mandatory changes must be made or the software may not behave as expected.
For more information, refer to the "Configuration File Management on SoundPoint
IP Phones" whitepaper at
3. Save the new configuration files and images (such as sip.ld) on the boot
server.
4. Reboot the phones by pressing the reboot multiple key combination.
For more information, refer to
Since the APPLICATION APP_FILE_PATH attribute of the <Ethernet
address>.cfg files references the individual sip.ld files, it is possible to
verify that an update is applied to phones of a particular model.
For example, the reference to sip.ld is changed to 2345-11605-001.sip.ld to
boot the SoundPoint IP 601 image.
The phones can be rebooted remotely through the SIP signaling protocol.
Refer to Special Events <specialEvent/>
The phones can be configured to periodically poll the boot server to check for
changed configuration files or application executable. If a change is detected,
the phone will reboot to download the change. Refer to
on page A-75.
With enhancements in BootROM 4.0.0 and SIP 2.1.2, you can modify the
000000000000.cfg or <Ethernet address>.cfg configuration file to direct
phones to load the software image and configuration files based on the phone
model number. Refer to
The SIP 2.2.0 or later software distributions contain both new distribution files
for the new release and a uniquely named version of the SIP 2.1.2 release files
that is compatible with SoundPoint IP 300 and 500 phones.
www.polycom.com/support/voice/ .
Multiple Key Combinations
on page A-15.
Master Configuration Files
on page C-9.
Provisioning <prov/>
on page A-2.
