Polycom SIP 2.2.0 Administrator's Manual page 179

Attribute
ind.pattern.x.step.y.state
ind.pattern.x.step.y.duration
ind.pattern.x.step.y.colour
Attribute
ind.class.x.state.y.index
Patterns <pattern/>
This section defines patterns for the LED indicators. In the following table, x is
the pattern number, y is the step in the pattern.
Permitted
Values
On or Off
positive integer
Red or Green
(default is Red if
not specified)
Classes <class/>
This section defines the available classes for the LED and graphical icon
indicator types. In the following table, x is the class number, y is the identifier
of the state number for that class.
Permitted
Values
positive integer
Assignments
This attribute assigns a type and a class to an indicator. In the case of the
Graphic Icon type, it also assigns a physical location and size in pixels on the
LCD display (refer to the following section). In the case of the LED type, it
assigns a physical LED number (refer to
<IP_330>, <IP_400/>, <IP_500/>, <IP_600/>, <IP_4000/>
Interpretation
Turn LED on or off for this step.
Duration in milliseconds for this step. 0=infinite
For bi-color LEDs, specify color.
Interpretation
For LED type indicators, index refers to the pattern index,
such as index x in the Patterns <pattern/>
For Graphic Icon type indicators, index refers to the
animation index, such as index y in the
<IP_300/>, <IP_330/>, <IP_400/>, <IP_500/>, <IP_600/>,
<IP_4000/> tag above.
Graphic Icons <gi/> <IP_300/>,
Configuration Files
tag above.
Animations <anim/>
on page A-68).
A - 67
