Basic Tcp/Ip <Tcp_Ip - Polycom SIP 2.2.0 Administrator's Manual

Administrator's Guide SoundPoint IP / SoundStation IP
Attribute
qos.ip.callControl.dscp
qos.ip.callControl.min_delay
qos.ip.callControl.max_throughput
qos.ip.callControl.max_reliability
qos.ip.callControl.min_cost
qos.ip.callControl.precedence
Basic TCP/IP <TCP_IP/>
A - 50
Call Control <callControl/>
These parameters apply to call control packets, such as the network protocol
signaling.
Permitted
Values
0 to 63 or
EF or
any of
AF11,AF12,
AF13,AF21,
AF22,AF23,
AF31,AF32,
AF33,AF41,
AF42,AF43
0, 1
0, 1
0, 1
0, 1
0-7
This attribute includes:
• Network Monitoring <netMon/>
• Time Synchronization <sntp/>
• Port <port/>
Default Interpretation
Null This parameter allows the DSCP of
packets to be specified. If set to a
value this will override the other
qos.ip.callControl...
parameters. Default of Null which
means the other
qos.ip.callControl...
parameters will be used.
1 If set to 1, set min-delay bit in the IP
TOS field of the IP header, or else
don't set it.
0 If set to 1, set max-throughput bit in
the IP TOS field of the IP header, or
else don't set it.
0 If set to 1, set max-reliability bit in
the IP TOS field of the IP header, or
else don't set it.
0 If set to 1, set min-cost bit in the IP
TOS field of the IP header, or else
don't set it.
5 If set to 1, set precedence bits in the
IP TOS field of the IP header, or
else don't set them.
