Polycom SIP 2.2.0 Administrator's Manual page 230

Administrator's Guide SoundPoint IP / SoundStation IP
C - 6
Model Width
IP 301 n/a
IP 320/330 225
IP 430 94
IP 501 114
IP 550/600/601 209
IP 650 209
IP 4000 150
Logos smaller than described in the table above are acceptable, but larger
logos may be truncated or interfere with other areas of the user interface.
The SoundPoint IP 500/501/550/600/601 phones only support the four colors
black, dark gray, light gray, and white. Any other colors will be approximated.
Color RGB Values (Decimal)
Black 0,0,0
Dark Gray 96,96,96
Light Gray 160,160,160
White 255,255,255
The SoundPoint IP 650 phones support a 16-bit grayscale, which is a smooth
gradient from black (0, 0, 0) to white (FF, FF, FF).
The SoundStation IP 4000 phone only supports black and white. Any other
colors will be rendered as either black or white.
Configuration File Changes
In the <bitmaps> section of sip.cfg, find the end of each model's bitmap list and
add your bitmap to the end; do not include the .bmp extension:
<bitmaps>
<IP_300 ... />
<IP_330 ... bitmap.IP_330.66.name="logo-330" />
<IP_500 ... bitmap.IP_500.66.name="logo-500" />
<IP_600 ... bitmap.IP_600.70.name="logo-600" />
<IP_4000 ... bitmap.IP_4000.70.name="logo-4000" />
Height Color Depth
n/a n/a
75 monochrome
23 monochrome
51 4-bit grayscale or
monochrome
109 4-bit grayscale or
monochrome
109 16-bit grayscale or
monochrome
33 monochrome
RGB Values
(Hexadecimal)
00,00,00
60,60,60
A0,A0,A0
FF,FF,FF
