Administrator's Guide SoundPoint IP / SoundStation IP
Attribute
ind.led.x.index
ind.led.x.class
ind.led.x.physNum
Attribute
ind.gi.x.y.index
ind.gi.x.y.class
ind.gi.x.y.physX
A - 68
LEDs <led/>
In the following table, x is the LED number.
Permitted
Values
Interpretation
This is for internal usage only and should not be changed (this is
the logical index).
positive integer
Assigns the class (defined in
this indicator.
This maps the logical index to a specific physical LED.
Graphic Icons <gi/> <IP_300/>, <IP_330>, <IP_400/>, <IP_500/>, <IP_600/>,
<IP_4000/>
In the following table, x=IP_300, IP_330, IP_400, IP_500, IP_600, IP_4000, y is
the graphic icon number. Note that IP_300 parameters affect SoundPoint IP
301 phones, IP_330 parameters affect SoundPoint IP 320 and 330 phones,
IP_400 parameters affectSoundPoint IP 430 phones, IP_500 parameters affect
SoundPoint IP 501 phones, and IP_600 parameters affect SoundPoint IP 550,
600, 601, and 650 phones, IP_4000 parameters affect SoundStation IP 4000
phones.
Permitted
Values
Interpretation
This is for internal usage only and should not be changed (this is
the logical index).
positive integer
Assigns the class (defined in
this indicator.
IP 300: 0-19
For Graphic Icon type indicators, this is the x-axis location of the
upper left corner of the indictor measured in pixels from left to
IP 330: 0-101
right.
IP 400: 0-122
IP 500: 0-159
IP 600: 0-319
IP 4000: 0-247
Classes <class/>
on page A-67) for
Classes <class/>
on page A-67) for
