Polycom SIP 2.2.0 Administrator's Manual page 39

Note
Name Possible Values
CDP Enabled, Disabled
VLAN ID Null, 0 through 4094
VLAN Filtering Enabled, Disabled
Storm Filtering Enabled, Disabled
LAN Port Mode 0 = Auto
1 = 10HD
2 = 10FD
3 = 100HD
4 = 100FD
PC Port Mode Auto, 10HD, 10FD, 100HD,
100FD
Note
The Server User and Server Password parameters should be changed from the
default values. Note that for insecure protocols the user chosen should have very
few privileges on the server.
Ethernet Menu
The following Ethernet configuration parameters can be modified on the
Ethernet menu:
The LAN Port Mode and PC Port Mode parameters are only available on
SoundPoint IP 330, 430, 550, 601, and 650 phones. HD means half duplex and FD
means full duplex.
It is recommended that you leave the LAN and PC parameters set to Auto.
Syslog Menu
Syslog is a standard for forwarding log messages in an IP network. The term
"syslog" is often used for both the actual syslog protocol, as well as the
application or library sending syslog messages.
Description
If enabled, the phone will use CDP. It also reports PoE
power usage to the switch. The default value is Enabled.
Phone's 802.1Q VLAN identifier. The default value is Null.
Note: Null = no VLAN tagging
Filter received Ethernet packets so that the TCP/IP stack
does not process bad data or too much data.
Enable/disable the VLAN filtering state.
The default value is Enabled.
Filter received Ethernet packets so that the TCP/IP stack
does not process bad data or too much data.
Enable/disable the DoS storm prevention state.
The default value is Enabled.
The network speed over the Ethernet.
The default value is Auto.
The network speed over the Ethernet.
The default value is Auto.
Setting up Your System
3 - 11
