Properties Of Saturated Steam Data - Honeywell AUTOMATIC CONTROL SI Edition Engineering Manual

GENERAL ENGINEERING DATA

PROPERTIES OF SATURATED STEAM DATA

Boiling Point
Pressure in or Steam
kPa Temperature
(absolute) C
1 6.98
5 32.90
10 45.83
50 81.35
60 85.95
70 89.96
80 93.51
90 96.71
100 99.63
101.3 100.00
150 111.37
200 120.23
250 127.43
300 133.54
350 138.87
400 143.62
450 147.92
500 151.84
600 158.84
700 164.96
800 170.41
900 175.36
1000 179.88
1100 184.07
1200 187.96
1300 191.61
1400 195.04
1500 198.29
1600 201.37
1700 204.31
1800 207.11
1900 209.80
2000 212.37
2500 223.94
3000 233.84
4000 250.33
5000 263.91
6000 275.55
7000 285.79
8000 294.97
9000 303.31
10000 310.96
11000 318.05
12000 324.65
13000 330.83
14000 336.64
15000 342.13
20000 365.70
22000 373.69
Table 20. Properties of Saturated Steam.
Specific V
Volume (V), (For valve
3
m /kg sizing)
129.20 11.3667
28.19 5.3094
14.67 3.8301
3.240 1.8000
2.732 1.6529
2.365 1.5379
2.087 1.4446
1.869 1.3671
1.694 1.3015
1.673 1.2934
1.159 1.0766
0.8854 0.9410
0.7184 0.8486
0.6056 0.7782
0.5240 0.7239
0.4622 0.6799
0.4138 0.6433
0.3747 0.6121
0.3155 0.5617
0.2727 0.5222
0.2403 0.4902
0.2148 0.4635
0.1943 0.4408
0.1774 0.4212
0.1632 0.4040
0.1511 0.3887
0.1407 0.3751
0.1317 0.3629
0.1237 0.3517
0.1166 0.3415
0.1103 0.3321
0.1047 0.3236
0.09954 0.3155
0.07991 0.2827
0.06663 0.2581
0.04975 0.2230
0.03943 0.1986
0.03244 0.1801
0.02737 0.1654
0.02353 0.1534
0.02050 0.1432
0.01804 0.1343
0.01601 0.1265
0.01428 0.1195
0.01280 0.1131
0.01150 0.1072
0.01034 0.1017
0.00588 0.0767
0.00373 0.0611
Maximum
Allowable
Pressure Drop,
kPa. (For valve Heat of the
sizing) Liquid, kJ/kg
0.5 29.34
2.5 137.77
5.0 191.83
25.0 340.56
30.0 359.93
35.0 376.77
40.0 391.72
45.0 405.21
50.0 417.51
50.7 419.06
75.0 467.13
100.0 504.70
125.0 535.34
150.0 561.43
175.0 584.27
200.0 604.67
225.0 623.16
250.0 640.12
300.0 670.42
700.0 697.06
400.0 720.94
450.0 742.64
500.0 762.61
550.0 781.13
600.0 798.43
650.0 814.70
700.0 830.08
750.0 844.67
800.0 858.56
850.0 871.84
900.0 884.58
950.0 896.81
1000.0 908.59
1250.0 961.96
1500.0 1008.4
2000.0 1087.4
2500.0 1154.5
3000.0 1213.7
3500.0 1267.4
4000.0 1317.1
4500.0 1363.7
5000.0 1408.0
5500.0 1450.6
6000.0 1491.8
6500.0 1532.0
7000.0 1571.6
7500.0 1611.0
10000.0 1826.5
11000.0 2011.1
ENGINEERING MANUAL OF AUTOMATIC CONTROL
476
Latent Heat Total Heat
of Evap., of Steam,
kJ/kg kJ/kg
2485.0 2514.4
2423.8 2561.6
2392.9 2584.8
2305.4 2646.0
2293.6 2653.6
2283.3 2660.1
2274.0 2665.8
2265.6 2670.9
2257.9 2675.4
2256.9 2676.0
2693.4 2693.4
2706.3 2706.3
2716.4 2716.4
2724.7 2724.7
2731.6 2731.6
2737.6 2737.6
2742.9 2742.9
2747.5 2747.5
2755.5 2755.5
2762.0 2762.0
2667.5 2667.5
2772.1 2772.1
2776.2 2776.2
2779.7 2779.7
2782.7 2782.7
2785.4 2785.4
2787.8 2787.8
2789.9 2789.9
2791.7 2791.7
2793.4 2793.4
2794.8 2794.8
2796.1 2796.1
2797.2 2797.2
2800.9 2800.9
2802.3 2802.3
2800.3 2800.3
2794.2 2794.2
2785.0 2785.0
2773.5 2773.5
2759.9 2759.9
2744.6 2744.6
2727.7 2727.7
2709.3 2709.3
2689.2 2689.2
2667.0 2667.0
2642.4 2642.4
2615.0 2615.0
2418.4 2418.4
2195. 2195.6
