Qlogic SANsurfer FC HBA Manager User Manual page 99

A
SN0054651-00 G
Do not allow selected LUN to be enabled (no LUN sharing
allowed)
This policy does not enable the selected LUN.
If you select this policy and SANsurfer detects this type of
sharing, it displays a warning message. Do one of the following:
For your system to unconfigure the LUN, click OK.
To view which LUNs are being shared with hosts that are
conflicting with this policy, click More.
Configure the selected LUN(s) and disable access from
other hosts.
This policy configures the selected LUN and disables access to
the LUN from other hosts.
If you select this policy and SANsurfer detects this type of
sharing, it displays a warning message. Do one of the following:
To disable access to these LUNs from other hosts that
display in the FC/CNA HBA tree, click OK.
To disable this policy for this instance, click Cancel.
To view which LUNs are being shared with hosts that are
conflicting with this policy, click More.
Enable the selected LUN and display a message if the LUN is
already enabled on another host(s).
This policy enables the selected LUN and shows a message if
the LUN is enabled on another host.
If you select this policy and SANsurfer detects this type of
sharing, it displays a warning message. Do one of the following:
To disable access to these LUNs from other hosts, click
OK.
To disable this policy for this instance, click Cancel.
To view which LUNs are being shared with hosts that are
conflicting with this policy, click More.
Ask these options when a LUN is enabled and sharing is
detected.
If you select this policy and ANsurfer detects sharing, the Shared
Device Found dialog box opens
following options:
Do not configure device.
Configure and disable access from other hosts.
Getting Started
Setting the Configuration Policies
(Figure 5-12). Click one of the
5-27
