The recommended workflow for identifying and correcting EAPS configuration problems from within
the EPICenter EAPS Monitor is as follows:
1 Run the Verify EAPS command.
2 If there are errors in the Verification Report, you can click the domain or device link in the source
column, and this will put you into Focus Mode for the domain or device where the errors occurred.
3 From a highlighted device node on the EAPS map, you can run the EAPS Log Report, which may
contain much information useful in debugging these issue. (Just move the cursor over the device
node and the resulting pop-up contains a link to generate the EAPS Log Report.)
4 From the highlighted device node on the EAPS map, right-click to bring up the pop-up menu, then
select Device > Telnet. This opens an interactive Telnet session on the device, without exiting the
EAPS Monitor application. This means you can execute CLI commands on the device to correct a
configuration problem, while still viewing the EAPS Verification Report and the EAPS map showing
the highlighted device or domain.
5 When you have fixed the problems via the ExtremeWare or ExtremeXOS CLI, you can close the
Telnet applet, and then Refresh the EAPS Verification Report to see the results of your corrections.
NOTE
It may take multiple iterations of correcting errors and running the verification report to produce a correct EAPS
configuration, as correcting one set of configuration errors may reveal other errors. You should continue to re-run the
verification process until no errors are reported.
To run a verification on your EAPS domains, click Verify EAPS under the Tools menu. Depending
●
on the size of your network and your EAPS configurations, this can take as long as 15 minutes.
The results of the verification are shown in the EAPS Verification Results window.
Figure 41: EAPS Verification Results
