Configuring Devices for Use With EPICenter
Table 9: Tags used for Telnet integration
TAG
CLI.MORE_PROMPT
The
3Com.xml
<?xml version="1.0" encoding="utf-8" ?>
<deviceType name="3Com"
<identity>
<sysObjectID protocol="SNMP">43</sysObjectID>
</identity>
<attributes>
<vendor>3Com</vendor>
<imageIconsFileName>3comicons.gif</imageIconsFileName>
<CLI.LOGIN_PROMPT> login: </CLI.LOGIN_PROMPT>
<CLI.PASSWORD_PROMPT> password: </CLI.PASSWORD_PROMPT>
<CLI.SHELL_PROMPT> [#>$] </CLI.SHELL_PROMPT>
<CLI.MORE_PROMPT> Press|to continue or|to quit: </CLI.MORE_PROMPT>
<TELNET_MACROS> true </TELNET_MACROS>
</attributes>
</deviceType>
Note that in the case of 3COM, the Telnet integration is handled at the device type level, since it is the
same for all the 3COM devices. Therefore, it is not duplicated in each device ATL XML file, but
handled one at the device type (enterprise) level.

Alarm Integration

Alarm Integration for a 3rd party device will enable EPICenter users to create Alarms based on trap
events from the 3rd party device. There are five steps to integrating 3rd party alarms:
1 The trap OID for each event must be added to the
2 The necessary MIBs must be placed in the
3 The 3rd party MIB filenames must be specified in the
4 Restart the EPICenter server
5 Each 3rd party device must be configured to send traps to EPICenter. See
Trap Receiver" on page 196
Once this is done, the 3rd party event(s) should be selectable from the Event Name drop down list on
the Basic tab of the Alarm Definition Window (in the Alarm Manager). Alarms can then be defined to
take actions upon the occurrence of these events.
202
Value
Provide the pattern that
matches the prompt used by
the device to prompt when
paging is enabled on the
device.
file provides an example of the prompts used for Telnet integration:
version="1"
parent="3rd Party">
for information on how to accomplish this.
Comments
This tag is optional.
file
events.xml
extreme.war/thirdPartyMibs
miblist.txt
directory
file in the directory
extreme.war
"Setting EPICenter as a
