Table 17: VlanMgr command options (continued)
Option
-port <ports>
-tagport <ports>
-ipf
-ip <IP address>/<subnet
mask>
-tag <number>
-protocol <protocol
name>
Delete VLAN:
-delete <VLAN name>
You can specify only one EPICenter server (database) in a command. If you want to create, modify
●
or delete VLANs for devices managed by multiple EPICenter servers, you must use a separate
command for each server.
To create a VLAN on multiple switches, use multiple
●
The option effectively recreates a VLAN with only the options specified in the command.
●
-modify
Any options not specified are reset to their defaults, and only devices specified with a
the modify command will be included in the VLAN.
WARNING!
Only the devices that are explicitly included in a VlanMgr modify command will be included in the modified
VLAN. Any devices in the original VLAN that are not specified in the modify command will be removed from the
VLAN as a result of the modify command. Any options that are not explicitly specified will be reset to their
defaults.
For example, suppose you have untagged VLAN Test1 that includes ports 2, 3,and 4 on device
10.20.30.40. To add ports 1 and 2 on device 10.20.30.50 to the VLAN, you can use the
command, but the command must specify both
10.20.30.40 -port 2,3,4
and its ports will be removed from the VLAN.
EPICenter Concepts and Solutions Guide
Value
Ports to be included in the VLAN as untagged
ports on the device specified by the preceding
-dip option. If this option is not included, any
untagged ports configured on this device will
be removed from the VLAN.
Ports to be included in the VLAN as tagged
ports on the device specified by the preceding
-dip option. If this option is not included, any
tagged ports configured on this device will be
removed from the VLAN.
Enable IP forwarding on the specified device. If
this option is not included, IP forwarding will
be disabled on this device.
Set an IP address and submask for this VLAN
on the specified device. Format is xx.xx.xx.xx/
nn. If this option is not included, the VLAN will
be reconfigured without a VLAN IP address.
Set a tag value for the VLAN. This can be a value between 2 and
4095. If this option is not included, the VLAN will be reset to an
untagged VLAN.
Set protocol filter. If this option is not included, the protocol will be
reset to ANY.
Delete the specified VLAN from all switches on which it is
configured.
-dip 10.20.30.50 -port 1,2
. If you do not include device 10.20.30.40 in the command, that device
These options
must immediately
follow the -dip
option to which
they apply.
Each option may
be specified once
per -dip option.
options in a single command.
-dip
The VlanMgr Utility
Default
No
untagged
ports
No tagged
ports
IP
forwarding
disabled
No IP
address
Untagged
ANY
None
option in
-dip
-modify
and
-dip
