System Map: Bottom View - Model B

Battery Information
Always completely dis-
charge, then fully charge, a
new battery before using it.
Completely discharge and
charge the battery at least
once every 30 days or after
about 20 partial discharges.
See "Energy Star Power
Saving" on page 3 - 10
full instructions.
The CPU is not a user serviceable part.
To prevent your computer from overheating make sure nothing blocks the Vent/Fan Intake
while the computer is in use.
4
for
CPU
Overheating
1
3
2
3 3
System Map: Bottom View - Model B 1 - 17
Quick Start Guide
Figure 1 - 9
Bottom View
(Model B
Computers)
1. Battery
2. RAM & CPU Bay
Cover
3. Vent/Fan Intake/
Outlet
4. Hard Disk Bay
Cover
Note: the 3.75G/HSPA
USIM Card is located un-
der the RAM & CPU Bay
Cover.
