5. Gently pull the two release latches on the sides of the memory socket in the
direction indicated by the arrows (
6. The RAM module will
7. Pull the latches to release the second module if necessary.
8. Insert a new module holding it at about a 30° angle and fit the connectors firmly
into the memory slot.
6
9. The module's pin alignment will allow it to only fit one way. Make sure the module
is seated as far into the slot as it will go. DO NOT FORCE the module; it should fit
without much pressure.
)
& in Figure 6 -
6 7
pop-up, and you can remove it.
8
7
Upgrading The Computer
9.
8
Upgrading the System Memory (RAM) 6 - 11
Figure 6 - 9
RAM Module
Removal
Single Memory
Module Installation
If your computer has a
single memory module,
then insert the module
into the Channel 0
(JDIMM1) socket. In this
case this is the lower
memory socket (the
socket closest to the
mainboard).
