Modules & Options
Figure 7 - 30
Insert the USIM
Card
7
Figure 7 - 31
SIMLOCK Lock
Cover Pins
Note that Model B has
cover pins that need to be
aligned with slots in the
case to insure a proper
cover fit, before screwing
down the bay cover.
7 - 36 3.75G/HSPA Module
5. Insert the USIM card as you would into your mobile phone.
6. Slide the SIMLOCK towards the hinge (in the opposite direction to the arrow
illustrated in Figure 7 -
7. Insert the USIM card as illustrated in
8. Lock the SIMLOCK by pushing it in the direction of the arrow in
it clicks into the lock position.
Model A
9. Replace the covers and screws (reconnect the fan cable before screwing down
the bay cover for Model B computers - see sidebar for note on cover pins).
31) in order to release the lock and lift it up.
(Figure 7 - 30) and close the SIMLOCK.
Model A
Model B
Figure 7 - 31 until
