Upgrading The Computer
Fan Cable & Cover
Make sure you recon-
nect the fan cable
before screwing down
the bay cover. Note the
information on replacing
the RAM & CPU bay
cover in "Cover Pins"
6
on page 6 - 12.
Contact Warning
Be careful not to touch
the metal pins on the
RAM module's connect-
ing edge. Even
cleanest hands
oils which can attract
particles, and degrade
the module's perfor-
mance.
Figure 6 - 8
CPU/RAM Bay
Cover Removed
6 - 10 Upgrading the System Memory (RAM)
3. Carefully (a fan and cable are attached to the under side of the cover) lift up
the bay cover.
4. Carefully disconnect the fan cable
4
the
have
, and remove the cover
4
Model A
4
Model B
5
4
.
5
5
