EUROCOM Notebook V09.2.00 User Manual page 102

Upgrading The Computer
Figure 6 - 4
6
HDD Cover
Removal
6 - 6 Upgrading the Hard Disk Drive
6. Remove the screw(s)
7. Reverse the process to install a new hard disk drive (do not forget to replace all the
screws and covers).
Model B
Model A
(for Model B only) and the adhesive cover
6
6
Hard Disk Screws &
The hard disks and cov-
7
ers pictured here may
appear slightly different
from your model design
(these designs are sub-
ject to change and up-
grade without notice).
Pay careful attention to
the screws (if included)
and cover orientation.
7
.
7
Cover
