ATI Video Driver Controls
Figure B - 5
HDMI Device
B
B - 6 Attaching Other Displays

HDMI Audio Configuration

HDMI (High-Definition Multimedia Interface) carries both audio and video signals
and you will can configure the audio output as per the instructions below when an
HDMI enabled device is connected to the HDMI-Out port.
Windows Audio Setup for HDMI
1. Connect a device with HDMI support to the HDMI-Out port.
2. Click Start, and click Control Panel (or point to Settings and click Control Panel).
3. Click Sound (Hardware and Sound).
4. Click Playback (tab), and click to select Digital Output Device (HDMI).
5. Double-click Digital Output Device (HDMI) (or right-click the icon and select
Properties).
Click the taskbar volume in-
dicator when HDMI De-
vice is selected, and you will
note that the icon at the top of
the volume level indicator
has changed.
