Processor; Core Logic; Display; Memory - EUROCOM Notebook V09.2.00 User Manual

Specifications

Processor

Intel® Core i7-820QM Processor:
1.73GHz
45nm (45 Nanometer) Process
Technology, 8M L3 Cache &
FSB 1333MHz - TDP 45W
rPGA988 Package
Intel® Core i7-720QM Processor:
1.6GHz
45nm (45 Nanometer) Process
Technology, 6M L3 Cache &
FSB 1333MHz - TDP 45W
rPGA988 Package

Core Logic

Intel® PM55 Chipset

Display

Model A Computers:
17" WXGA(1440 * 900) / WUXGA (1920 *
1200) TFT LCD
C
Model B Computers:
15.6" HD 16:9 Wide Screen (1366 * 768)
/ HD+(1600 * 900) / FHD (1920 * 1080)
TFT LCD
C - 2 Specifications

Memory

Dual Channel DDRIII (DDR3)
Two 204 Pin SO-DIMM Sockets
Supporting DDRIII (DDR3) 1066/1333MHz
Memory Expandable up to 4GB
(1GB / 2GB DDRIII (DDR3) Modules)

Video Adapter

ATI Mobility Radeon HD 4570 Discrete
Graphics On Board (PCIe 2.0 * 8)
512MB GDDR2 Video RAM on board
Supports Microsoft DirectX ® 10
Supports HDCP

BIOS

One 32Mb SPI Flash ROM
Phoenix™ BIOS

Storage

One Changeable 12.7mm(h) Optical
Device (CD/DVD) Type Drive (see
"Optional" on page C - 4)
Easy Changeable 2.5" 9.5 mm (h) SATA
(Serial) HDD

Audio

High Definition Audio Compliant Interface
3D Stereo Enhanced Sound System
S/PDIF Digital Output
Built-In Microphone
Ω
2 * Built-In Speakers 1W, 8
Keyboard & Pointing Device
Full Size WinKey Keyboard
Built-in TouchPad (integrated scrolling
key functionality) with Multi Gesture
Function
Three Instant Keys (WWW, E-Mail, Silent
Mode)

Card Reader

Embedded 7-in-1 Card Reader (MS/ MS
Pro/ SD/ Mini SD/ MMC/ RS MMC/ MS
Duo) Note: MS Duo/ Mini SD/ RS MMC
Cards require a PC adapter
