Upgrading The Computer
Cover Pins
Note that there are cov-
er pins need to be
aligned with slots in the
case to insure a proper
cover fit, before screw-
ing down the bay cover
(see Figure 6 - 10).
6
Figure 6 - 10
Cover Pin
Alignment
6 - 12 Upgrading the System Memory (RAM)
10. Press the module in and down towards the mainboard until the slot levers click into
place to secure the module.
11. Replace the bay cover (see sidebar and below for Model A Computers) and
screws (make sure you reconnect the fan cable before screwing down the
bay cover).
Model A
12. Restart the computer to allow the BIOS to register the new memory configuration
as it starts up.
Model B
