Figure 7 - 7
RAID Jumper Location
7
7 - 18 RAID Configuration
Jumper Setting for RAID/ATA Configuration
1.
Follow the procedure to remove the secondary hard disk (see
the Hard Disk(s)" on page 6 -
2.
Locate the jumper at point
3.
Use a bent paper clip to push the switches up to ON for RAID mode, or
down to off for ATA mode.
5).
.
1
1
2
3
"Upgrading
