YourProScan television ismore than state-of-the-art
technology.
It's technology tailored to you. Features
des!igned to deliver viewing and listening enjoyment beyond
expectations. Innovation and simplicity of operation become
one-ProScan.
Improving Your Image
• IDTV (Improved Definition TV): High tech video processing
gives you twice the number of video scan lines as conventional
TVs for superior picture quality.
• A Brighter Picture: Advanced picture tube design incorporates
Invar alloy to maintain excellent picture purity, even under the
brightest conditions, allowing for more light output than
conventional tubes.
• No Glare
TM
Picture: Anti-Glare Lithium Silicate Faceplate
reduces glare while enhancing contrast.
• A Cleaner Picture: The Digital Comb Filter reduces distortion
and extends resolution.
• A Cleaner Picture Tube: The Anti-Static Faceplate reduces the
static that attracts dust.
• Greater Contrast: Dynamic Gamma Correction automatically
extends the dynamic range of the luminance signal, producing
blacker blacks and whiter whites.
• Increased Clarity: Edge Replacement and Scan Velocity
Modulation enhance image edges. That along with dynamic focus
give you crisp clean details-with up to 600 lines of horizontal
resolution.
Sound Thinking
• Flexibility: Eight different audio modes built right into the TV.
From basic stereo, to Dolby* 3 stereo, to Dolby* prologic, and all
the steps between. For details, see pages 22-36.
• Acoustic Suspension Speaker System sealed enclosures and high
compliance speakers provide higher fidelity and extended bass
response.
• C,n-Screen Graphic Equalizer permits precise adjustment of
seven frequency bands to complement your room's acoustics.
For details, see pages 26-27.
• 10 Watts Per Channel **
• dbx*** Noise Reduction
• Second Audio Program (SAP) For details, see page 30.
*Dolby is a registered trademarkof Dolby LaboratoriesLicensing Corp.
**RMS rating, into 8 ohms, 50 to 20,000 Hz _+3db,with less than
1%THD.
***dbx is a registered trademarkof Carillon Electronics Corp.
Creative Entertainment
• DVE (Digital Video Effects) lets you control the speed of mosaic
and solarization effects on the large picture. For details, see page 16.
• Advanced Color Picture-ln-Picture using two tuners lets you
watch two programs at once. You can swap, freeze, move, or pan
either picture-for viewing convenience. You do not need a VCR
or external video source for additional picture. For details see
pages 18-21.
• Zoom - enlarges any desired video image for a closer look. Also
c]hanges the size of the inset Picture-In-Picture. For details, see
pages 14-15 and 18.
• Pan - allows you to move across the enlarged video image to
select any portion for viewing. For details, see pages 14-15.
• Channel Guide - displays a still picture from 12 different channels
at one time for a quick review of available programs.
For details, see page 17.
• C.hannel Labeling lets you label channels with one of over 100
built-in labels or create your own five-character label. For details,
see pages 48-49.
• Scheduler allows you to enter up to three separate programs to run
only once or to run at the same time every week. The TV will turn
on, tune to the selected channel, and turn off-all automatically.
For details, see pages 44-45.
• Commercial Skip For details, see page 11.
• Sleep Timer For details, see page 52.
• Parental Control For details, see page 50.
• Previous Channel Feature For details, see page 10.
• 181 Channel Tuning Capability in U.S.A.*
For details, see page 65.
* Check your cable company's compatibility requirements.
One Minute Manual
• On-Screen Menus for operation of all features.
• AutoProgramming automatically searches for and stores all active
channels. Eliminates the need for manual set-up. For details, see
page 46.
• Frequency Synthesis Tuning automatically and accurately tunes
each channel.
• Automatic VCR Setup: With the push of a button, your TV is
ready for VCR play: Both TV and VCR turn on, and TV tunes to
the correct channel or input. For details, see page 43.
• Automatic Cable Box Setup: With the push of a button, your TV
is ready for cable box operation: Both TV and cable box turn on,
and TV tunes to the correct channel or input.
For details, see page 43.
• On-Screen Clock/Channel Display For details, see page 7.
• Picture and Audio Reset For details, see pages 38-39.
• Auto Demos For details, see page 51.
Networking
Gold Plated Phono Jacks for Superior Performance:
• Two Sets of Audio/Video Inputs including S-VIDEO for VCR,
laser disc player, camcorder, etc. For details, see pages 66
and 68-69.
• One Set of Audio/Video Outputs including S-video for video
dubbing. For details, see pages 67 and 69.
• One Set of Volume-Controlled Audio Outputs (Hi Fi) to retain
remote volume when connected to an external amplifier.
For details, see page 70.
• One Volume-Controlled SURROUND Audio Output jack to
connect surround sound to an external amplifier. For details,
see page 71.
• One Volume-Controlled CENI"ER Audio Output jack to connect
center sound to an external amplifier. For details, see page 71.
Other Connections to Expand Your System:
• Four Speaker Jacks to allow hook up of optional external or
surround sound speakers. For details, see page 73.
• Dual RF Inputs to allow direct connection of up to twchbasic
cable, cable box, or other RF sources. For details, see
pages 41 and 61-63.
• Front-Mounted Stereo Headphone Jack for private listening
with optional headphones. For details, see pages 12 and 25.
At Your Command
Your ProScan television includes two remote controls.
• The ProScan Universal Remote: Operation is as easy as entering
a channel. It operates all major ProScan TV, VCR, and LaserDisc
player functions. It also operates the basic functions of 60 different
VCR brands and 28 different brands of cable boxes, eliminating the
need for additional remotes.
• The ProScan Simple Remote: 6 buttons control most TV
functions for the ultimate in simplicity.
At Your Service
Our Human Touch policy offers all these valuable benefits:
• 1-800-ProScan: Call our information service Monday through
Friday, 7 a.m. to 7 p.m. EST, year round.
Nationwide Authorized Independent Service Centers
ProScan Limited Warranty for L_.S.A.: In-home service of all
parts and labor for one year, picture tube for two years. For
details, see page 79. A separate warranty for Canada is enclosed
with all televisions sold in Canada.
