These modes provide surround sound generation and require
rear speakers. There are three surround modes to choose
from. Matrix surround simulates surround sound from a
menu broadcast. Hall surround provides surround sound from
;tereo signal, and stadium surround delays the rear sound
.onger than hall surround which gives you the feeling of being
in a larger area.
General R ecommended Speaker P lacement
forBestSurround Sound Audio
L Connectthese (optional) speakersto connectorslabeled 2
EXTERNAL on the back ofthe IV.
Connectthese speaker(s) to
speaker connector(s)labeled
SURROUND o nthe back of the IV, "-_
Surround Surround
Speaker ] Speaker ]
[,(Elevated)
(Elevated) ]
You can easily select
MATRIX SURROUND, HALL SURROUND, or
STADIUM SURROUND by repeatedly pressing the SURR(surround)
button on the master remote control. You can also select
Matrix, Hall, or Stadium surr with
the
AUDIO MODE menu
as
shown below. Then you can use the SURROUND S ETUPmenu to
adjust the functions to your personal preferences.
Selecting MatrixSurr,HallSurr, o rStadium SurrModes
1 Connect (optional) external speakers to the EXTERNAL
speaker connectors and surround speaker(s) to the
SURROUND c onnector(s) on the back of the TV. Details on
connecting speakers are on pages 72-73.
2 Display the AUDIO MODE menu.
1 Press MENUto display the
MAIN MENU.
2 Press + or - to highlight the
Audio Adjust function in
white.
3 Then press MENUagain to
display the AUDIO ADJUST
nlenu.
4 Press the + or - button to
highlight the Mode function.
5 Then press MENUto display
the AUDIOMODE menu.
6 Press + or- to highlight
Matrix surr, Hall surr, or
Stadium surr mode. Then
press MENU to turn on
whichever mode is
highlighted.
3 Press MENU again to exit the AUDIO MODE menu and return
to the AUDIO ADJUST menu.
Setup
will already be
higihlighted.
'tess the MENU button to enter the setup menu for the
ourround mode you have selected. If you have selected
matrix surround the setup menu is titled MATRIX SETUP. If
yOUhave selected hall or stadium surround the setup menu
is titled SURROUND.
L
5 Adjust the setup menu to your personal preference.
Press
+ or - to highlight the function.
• Press MENU when the Speaker,';: int/ext/off function is
highlighted to change the setting between Speakers: int
(internal), ext (external), or off:. Select Speakers: int to
hear sound from the TV's internal speakers. Select
Speakers: ext if you have external front speakers and you
want to hear the sound from them instead of the internal
speakers. Select Speakers: off if you do not want any
sound from the internal or external front speakers.
• Press MENU when Volume is highlighted to enter the
VOLUME d isplay. Press + to increase or.- to decrease the
TV's volume. This volume control raises and lowers the
volume of the internal, external, and surround speakers.
Note: If the VOLUMEdisplay stops before it is at full volume and
the volume is not high enough, check the Volume limiter to see if it
is set too low. Details are on page 24.
• Press MENU when the Balance function is highlighted to
enter the BALANCE adjustment display. Then press + or -
to adjust the left/right balance until the sound seems to
originate from a point halfway between the speakers.
• Press MENU when Rear spkr (speaker): on/off function is
highlighted to select either Rear spkr: on or Rear spkr: off.
Leave this function set to Rearspkr: on to hear surround
sound.
• Press MENU when Rear volume is highlighted to enter the
REAR VOLUME adjustment display. Press + to increase the
volume from the rear surround :_peakers or - to decrease
the volume from the rear surround speakers.
• Press
MENU
when the
Input
balancefunction is highlighted
to enter the INPUT BALANCE display. The INPUT BAL,t_CE
display is used to balance the left and right audio signals
coming into the set for optimum surround sound
performance. Most of the time you will want to leave
this at mid scale. If the sound coming from your
surround sound speaker(s) has a lot of voices (instead of
mostly background ambience), you may want to adjust
the INPUT BALANCE d isplay to minimize the voices. With
the INPUT BALANCE display on the TV screen, press the +
and - buttons to move to the right and to the left of the
scale. Stop at the point where voices are minimal in the
surround speaker(s).
• Press MENU when Done is highlighted to exit the setup
menu.
Saving,Restoring,and Returningto FactorySettings
The TV will remember your settings--even when you turn it
off. To prevent losing your personal settings because
someone changes them accidentally, you can save them using
the MEMORY M ENU. After the settings have been saved, you
can restore them at a later date using the MEMORY MENU.The
MEMORY M ENU also lets you easily restore the MATRIX S ETUP or
SURROUND s etup menu to its factory settings. Detail._ are on
page 39.
