ProScan PS35310 Owner's Manual page 12

After you connect another video source (like a VCR) to your
TV, you'll be able to display two different programs on the
TV at the same time. For example, two different football
games as shown below. You can also connect a video camera
or camcorder to use as a surveillance system for a baby's
room.
I-we Football Games
Surveillance System
Starting Picture-in-Picture (PIP)
1
Connect another video source (such as a VCR or
camcorder) to INPUTS 1 or iNPUTS 2 on your TV (as shown
on pages 45-47).
2 Turn on TV and select the TV channel you want to watch.
•If the other source is connected to the TV's INPUT Ijacks,
select TV channel 91 to see the signal. If you have
programmed the vcm (or VCR2) button to automatically
select channel 91 as described on page 23, press veal (or
VCR2).
• Select channel 92 if the other source is connected to the
TV's iNPUT 2 jacks. If you have programmed the VCR1 (or
VCR2) button to automatically select channel 92 as
described on page 23, press veal (or VCR2).
• Select channel 90 if the other source is connected to the
TV's S-VIDEO c onnector. (Remember to also connect the
regular video cable to the VIDEO INPUT 1jack for picturc-
in-picture viewing.). The TV automatically minimizes
any annoying differences in tint between the small and
large picture by electronically coupling the S-ViDEO input
to the INPUT 1 input. If you have programmed the VCR1
(or VCRa)button to automatically select channel 90 as
described on page 23, press Veal (or VCRZ).
Changing Channels (PIP)
To change channels on the picture from the TV, press the TV
button on the remote, and then press either the CHANNEL up
or down button or two number buttons.
Picture from TV
3
Press the PIPbutton on the remotc. A little picture will
appear on the screen. The little picture and the big picture
will be the samc.
To change channels on thc picture coming from the VCR,
press the veto or Yea2 button (if you've programmed one of
these buttons to control the VCR as described on page 29)
and then press either the CHANup or down button or two
number buttons. You can also change the VCR's picture by
pressing the CHANNEL buttons on the front of the VCR.
Note: The remote must bc in the "TV mode" when you press the PIP
button. To put rcmotc in "TV mode", press the TVbutton.
To get a picture from the other source (VCR, camcorder,
etc.), first turn on the other source, and then select TV
channel 90, 91, or 92 (explained at top of next column).
The picture from the other source will appear in the little
picture.
Picture from TV
Picture from VCR
Picture from VCR
Additional Features (PIP)
Whcncver thc picture-in-picture fcaturc is aclivalcd, lhc small
picture can be moved, frozen, or switched with the main
picture as desired. Details" are on the next page.
Caution: When using TV games, computers, and similar products with
your TV, keep the brightness and contrast functions at low settings. If a
fixed (non-moving) pattern is left on the screen for long periods of time
at a high brightness or contrast setting, the image can bc permanently
imprinted onto the screen. These types of imprints are not covered by
your warranty because they are the result of misuse.
