Sewing mode
In sewing mode view you can select stitches, adjust and sew them. You can also go to Stitch Creator and
to sequencing to create your own stitches and sequences. Your selected stitch will be shown in full scale in
the stitch fi eld. The recommendations and machine settings will be shown at the top.
Sewing mode - overview
1.
Sewing recommendations
2.
Machine settings
3.
Stitch selection area
4.
Scroll bar (Scroll through stitch
categories)
5.
Selected stitch number
6.
Stitch fi eld
7.
Mirroring side to side
8.
Mirroring end to end
9.
Sequence start position
10. Zoom to all
11. Stitch width
12. Width/position toggle
13. Stitch length
14. Stitch density
15. Needle thread tension
16. Save options
a) Save personal default stitch
b) Save to Personal menu
c) Save to Personal fi le
17. Tie-off options
a) Tie-off beginning
b) Tie-off end
c) Thread snips
18. Speed control
19. Sewing programs
20. Balance
21. Repeat buttonhole
22. Stitch positioning
23. Buttonhole slit length
24. Button stitch repetition
Note: All symbols and options will not be
shown at the same time.
4:2
1
2
5
6
9
7
8
21
3
10
16a 16b 16c
17a
17b 17c
11
13
14
15
12
22
23
24
4
16
17
18
19
20
