- Page 1 Embroidery preparations...
-
Page 2: Embroidery Unit Overview
D Embroidery unit socket Embroidery hoop connection assembly Embroidery arm Note: A smaller embroidery unit, 260x200mm, is available to purchase at your local authorized PFAFF® dealer. Embroidery unit accessory tray Use the tray in the embroidery unit to store accessories used for embroidering. -
Page 3: Connect The Embroidery Unit
creative vision™ Embroidery collection Page through the creative vision™ Embroidery collection for designs and fonts. The design number, stitch count (number of stitches in the design) and the design size are displayed next to each design. The suggested thread colors for each color number are shown. Connect the embroidery unit There is a covered socket behind the free-arm, see picture. -
Page 4: To Hoop The Fabric
To hoop the fabric For the best embroidery results, place a layer of stabilizer beneath the fabric. When hooping stabilizer and fabric make sure that they are smooth and securely hooped. Open the quick release (A) on the outer hoop. Remove the inner hoop. -
Page 5: Getting Started Embroidering
Getting started embroidering After attaching the embroidery unit and embroidery foot, insert a bobbin with lightweight bobbin thread. Note: Make sure that the IDT is disengaged. Hoop a piece of fabric and slide on Open selection menu (A) to select a design. Touch it once to load to embroidery edit. - Page 6 Clear suffi cient space to accommodate movement of the embroidery arm and the hoop. Hold the needle thread and touch the start/stop button (D) or the foot control. The machine starts embroidering. After stitching a few stitches, the machine stops and a pop-up appears on the screen asking you to cut the thread end.
