76 Chapter 5 - Upgrading the System
To define ISA boards with a configuration file:
1. Shut down and power off the system.
2. Insert the SYSUTIL diskette into the floppy diskette slot of the combo
drive; then restart the system.
3. When the MS-DOS Startup menu displays, select the System
Configuration Utility option.
4. Use the arrow keys or the mouse to select Step 2 from the SCU Main
Menu. Then press
not been installed yet.
A prompt displays, requesting you to copy the configuration files
needed to configure the system. The configuration file is on a diskette
provided by the ISA board manufacturer.
5. Press
ENTER
6. Select the slot where the board will be installed. Only slots 1 through
3 are valid for the desktop workstation.
7. When prompted to insert the source disk, insert the diskette containing
the configuration file and press
8. When prompted to insert the destination disk, insert the SYSUTIL
diskette and press
board manufacturer will be installed to the system and to the
SYSUTIL diskette.
9. Press
ESC
10. Select Step 4 to save the configuration, and then select Step 6 to exit
the SCU.
11. Remove the diskette from the combo drive; then restart the system.

ISA Boards without a Configuration File

Some ISA board vendors do not include configuration files with their boards.
For these boards, you must use the SCU to define the ISA board to the
to add a board that was not detected or has
INSERT
to accept A:\ as the path to the configuration file.
ENTER
. The configuration file from the option
ENTER
to return to the SCU Main Menu.
.
