4 Chapter 1 - Getting Started
4. Connect the mouse cable to the mouse port on the back of the base
unit. Refer to the following figure.
5. Connect the remaining cables, such as Ethernet (AUI or 10Base-T
ports), printer (parallel port), and modem cables (COM1 and COM2
ports) to their ports on the back of the base unit. Refer to the
following figure.
If you are using cables not supplied by Intergraph, you must use
shielded cables to prevent excessive electromagnetic interference
(EMI). Intergraph cables are designed to reduce the amount of EMI
produced by the system.
Fast
SCSI-2
AC Voltage
Switch
Note: The ports on the back on the base unit are labeled using PC 95
compliant icons.
Do not connect a MIDI or game cable to the Ethernet AUI port. This
will short out the local area network on which the system resides.
WARNING
Ethernet
AUI
Microphone
Line Out
WARNING
COM1
MIDI
COM2
Mouse
Keyboard
Ethernet 10Base-T
Parallel
