Welcome to the OutBack Extreme Rugged Water Resistant Inverter/Charger
The OutBack Extreme Rugged Water Resistant Inverter/Charger (hereafter called the Inverter) provides
120 Vac, 60 Hz, true-sine wave power, from a 24 Vdc battery source. It is designed for rugged operational
environments in an unprotected, uncontrolled climate. This equipment is intended for use on tracked and
wheeled vehicles, and above deck and other areas where it will be exposed to unfavorable conditions.
OutBack Power Systems does everything possible to assure the components you purchase will function
properly and safely when installed as instructed according to local and national electrical codes. Please read
all of the following instructions and the instructions that come with any other OutBack components that
make up your power system. Further instructions on individual Inverter setups as well as systems assemblies
are included with the FLEXware manuals.
This Owner's Manual covers the following information:
•
Safety
•
Inverter parts, standard and optional
•
Initial inspection of the component
•
Preparing the mounting surface
•
Fastening the Inverter to the mounting surface
•
General electrical information
•
Installing and programming the MATE2 System Controller and Display (hereafter called the MATE)
OutBack Extreme Rugged Water Resistant Inverter/Charger
•
Part Number OBX-IC2024S-120/60
•
2000VA/24VDC
•
120VAC/60Hz
•
30 amp AC transfer switch with neutral-ground bond switching
•
Environmentally protected unit
Each Inverter has a single phase output marked with this symbol:
Each Inverter puts out a sine wave waveform marked with this symbol:
