SUMMARY SETUP SCREENS

MAIN--------------------------------
12:00:30P
SUM STATUS SETUP ADV
SETUP------------------------------
choose category:
FX
SETUP/MATE/PAGE1--------------
mate code rev
choose category
CLOCK CNT GLOW
SETUP/MATE/PAGE2--------------
choose category:
PG1 SUMRY COM
SETUP/MATE/SUMMARY----------
summary control
BACK TYPE DELAY ROLL
SETUP/MATE/SUMMARY---------
summary control
BACK TYPE DELAY
To program the operation of the SUMMARY screen, press the
<SETUP> soft key from the MAIN screen.
Press the <MATE> soft key to enter the series of menus for MATE
setup and display.
MATE
From the SETUP/MATE/PAGE1 screen, press the <PG2> soft
4.1.6
key. The other items on PAGE1 do not normally need to be
adjusted.
PG2
From the SETUP/MATE/PAGE2 Setup choices screen, press the
<SUMRY> soft key.
MAIN
Pressing the <SUMRY> soft key brings up the screen SETUP/
MATE/SUMMARY (summary control) and the screen options
<TYPE>, <DELAY> and <ROLL>.
To select the automated SUMMARY screen, see below.
To select the delay timing of the automated SUMMARY screen,
see the next page.
To choose the SUMMARY screen you want to view automatically
and also view from the MAIN menu, press the <TYPE> soft key
on the SETUP/MATE/SUMMARY screen.
ROLL
21
