INVERTER DEFAULT VALUES (subject to change with upgrades)
24 VDC System
Float Voltage
Absorb Voltage
EQ Voltage
ReFloat
LBCO
Absorb Time
EQ Time
Float Time
Charger Draw
AC1/Grid Transfer Delay
AC2/Gen Transfer Delay
Grid Lower Limit
Grid Upper Limit
Grid Connect Delay
Gen Lower Limit
Gen Upper Limit
AC DROP or USE
Charger OFF/AUTO/ON
Search Threshold
Search Pulses
Search Pulse Spacing
Stacking Phase
InPut Select
Grid Input Settings
Gen Input Settings
Set Output Voltage
36
DEFAULT MINIMUM
27.4 Vdc 24 Vdc
29.4 Vdc 26 Vdc
28.8 V 28 Vdc
25 Vdc 22 Vdc
21 Vdc 18 Vdc
2.0 hours 0.0 hours
1.0 hours 0.0 hours
1.0 hours 0.0 hours
5 Aac 0 Aac
6 AC cycles 0 AC cycles
60 AC cycles 0 AC cycles
108 Vac 40 Vac
140 Vac 130 Vac
0.5 min 0.2 min
108 Vac 40 Vac
140 Vac 130 Vac
USE N/A
AUTO N/A
6 watts 0 watts
8 2
60 AC cycles 4 AC cycles
1 or 2 phase N/A
Gen N/A
28 Aac 5 Aac
28 Aac 2 Aac
120 Vac 115 Vac
MAXIMUM
30 Vdc
32 Vdc
34 Vdc
26 Vdc
24 Vdc
24.0 hours
24.0 hours
24.0 hours
7 Aac
240 AC cycles
240 AC cycles
115 Vac
150 Vac
15.0 min
115 Vac
150 Vac
N/A
N/A
50 watts
20
120 AC cycles
N/A
N/A
30 Aac
30 Aac
125 Vac
