SETUP SCREENS

The Setup screens allow you to change several settings, to make your system run more smoothly. You can
program the amperage size of the AC source, to keep the Inverter from overdrawing a generator. You can
program the Summary screen to pop up automatically like a computer screensaver. In advanced systems,
you can order the MATE to search for any new devices, in case it has lost communication with the Inverter.
MAIN--------------------------------
12:00:30P
SUM STATUS SETUP ADV
SETUP------------------------------
choose category:
FX
SETUP/FX---------------------------
choose category:
SRCH INPUT
SETUP/FX/INPUT--------------P01
ac transfer
control
DOWN GRID
SETUP/FX/INPUT--------------P01
ac1/grid
limit
DOWN INC
SETUP/FX/INPUT--------------P01
ac2/gen
limit
DOWN INC
20
To program the size of an AC source, press the <SETUP> soft key
from the MAIN screen.
Press the <FX> soft key to enter the series of menus for Inverter
options (referred to here as FX options).
MATE
From the SETUP/FX screen, press the <INPUT> soft key. (The
SRCH option is not normally required to be used with the
OBX-IC2024S-120/60 Inverter.)
MAIN
From the SETUP/FX/INPUT screen, you can tell which of two
source sizes the Inverter should use. (The next items allow you
Grid
to set the sizes.) To use grid (utility) power for a certain size,
press the <GRID> soft key. To select a generator, press the
GEN PORT
<GEN> soft key. (The <PORT> soft key is only used if there are
multiple Inverters.)
When finished, press the <DOWN> soft key.
To select a grid source of a certain size, press either the <INC>
or <DEC> soft keys as appropriate until the value reaches
30.0 aac
the correct number. When finished, or if you want to set the
generator value instead, press the <DOWN> soft key.
DEC PORT
To select a generator of a certain size, press either the <INC>
or <DEC> soft keys as appropriate until the value reaches the
30.0 aac
correct number. When finished, press the <DOWN> soft key.
The next menu will allow you to either return to the top, return
DEC PORT
to the setup menu, or return to the Main screen.
