Reading a Status Screen
STATUS/FX/PAGE1---------------
choose category
MODES METER
• MODES : not recommended for use with the OBX-IC2024S-120/60 Inverter -- do not select this option
• METER : displays inverter and charger activity, including output and input AC voltage, and AC inverter,
charger, and input current
• BATT : displays the battery temperature, voltage and the various set points for the different recharging
cycles as well as the time remaining to complete any of those cycles
: pressing the <PG2> soft key opens the next selection of STATUS screens
• PG2
• ERROR : various errors and their causes, some external and some internal to the Inverter; an error can
shut the unit down
• WARN (ING): various warning situations, some external and some internal to the Inverter; warnings will
not shut the unit down
: Pressing the <PG3> soft key opens the last STATUS screen
• PG3
• DISCON : lists the reasons the Inverter disconnects from an AC source
• SELL : not used with the OBX-IC2024S-120/60 Inverter -- do not select this option
MAIN : exits STATUS and returns to the Main menu
•
26
STATUS/FX/PAGE2---------------
choose category
BATT PG2 PG1 ERROR
STATUS/FX/PAGE3---------------
choose category
WARN PG3 PG2 DISCON SELL MAIN
