INSTALLATION CHECK LIST

ITEM
Manual read and reviewed?
System mounted with the recommended number and sized fasteners?
System installed according to required codes and regulations?
System inspected?
System grounded?
Inverter output connected to load circuit with 30 AC amp maximum overcurrent protection?
Inverter AC sources protected with 30 AC amp maximum overcurrent protection?
Per the instructions regarding neutral and ground installation on page 7,
If the installation is non-bonded,
Inverter green/yellow wire connected?
Input and output neutral wires isolated from each other?
Generator's neutral and ground bonded together?
OR
If the installation is bonded,
Inverter green/yellow wire disconnected?
Input and output neutral wires on a common bus?
Generator's neutral and ground isolated from each other?
All cables torqued to OutBack specifications?
Battery connections to 10 foot-lbs/13.55 Nm?
Inverter DC terminals to 5 foot-lbs/5.8 Nm?
Inverter DC terminals and all exposed conductors coated in dielectric grease?
YES NO
33
