OBX-IC2024S-120/60 Inverter/Charger Specifications

Nominal DC Input Voltage Range
Nominal AC Voltage / Frequency
Continuous Power Rating at 25°C Ambient
Continuous AC RMS Output at 25°C
Idle Power - Full AC Output
Idle Power - Search Mode
Typical Efficiency
Total Harmonic Distortion - Typical
Output Voltage Regulation
Maximum Output Current – Peak (1 mSec)
Maximum Output Current - RMS (100 mSec)
AC Overload Capability - Surge
AC Overload Capability - 5 Second
AC Overload Capability - 30 Minutes
AC Input Current Maximum
AC Input Voltage Range
AC Input Frequency Range
DC Input Range
DC Input Current – Rated Power
Maximum DC Input Surge Current
Continuous Battery Charger Output
Recommended DC Voltage Range
24V Systems
Maximum DC Input Current
Note: This is the maximum DC current the Inverter will draw from the battery when starting very large AC loads. It
is not used for sizing the DC disconnect or selecting DC cable gauge. It is used to select the minimum reasonable
battery capacity.
OBX-IC2024S-120/60 Inverter
Rated DC Input Current
Note: This is the maximum continuous DC current that the Inverter will draw from the batteries when inverting.
OBX-IC2024S-120/60 Inverter
34
24 Vdc
120 Vac / 60 Hz
2000 VA
16.7 Aac
≈ 20 watts
6 watts
92%
2%
± 2%
70 Aac
50 Aac
6000 VA
4800 VA
3200 VA
30 Aac
80 to 150 Vac
54.0 to 66.0 Hz
21.0 to 34.0 Vdc
100 Adc
300 Adc
55 Adc
21 – 34 Vdc
300 Adc
100 Adc
