SETUP/MATE/SUM/TYPE---------
summary
screen type
BACK INC
SETUP/MATE/SUM/TYPE---------
summary
screen type
BACK INC
NOTE: Other options in this menu are not normally used with the OBX-IC2024S-120/60 Inverter.
SETUP/MATE/SUM/TYPE---------
summary
screen type
BACK INC
SETUP/MATE/SUMMARY----------
summary control
BACK TYPE
SETUP/MATE/SUMMARY----------
summary control
BACK TYPE
SETUP/MATE/SUMMARY----------
summary control
BACK TYPE
22
Press either the <INC> and <DEC> soft keys to change the
SUMMARY screen to one of the following items:
None
None — disables the SUMMARY screen from automatically
DEC
opening; the SUMMARY screen can still be accessed via the
<SUM> soft key on the MAIN screen.
FX Only—the SUMMARY screen for the Inverter is enabled and
will open after a delay time (see below).
FX Only
Continuing to press either the <INC> or <DEC> soft keys will
bring up other summary screen options.
DEC
Press the <BACK> soft key to return to the Summary
Control screen.
FX Only
DEC
The <DELAY> soft key sets the time delay for the SUMMARY
screen to appear. (See below and the next page.)
The <ROLL> soft key is not normally used with the
DELAY ROLL
OBX-IC2024S-120/60 Inverter.
After selecting FX Only and exiting the SETUP/MATE/SUM/
TYPE screen, the SUMMARY screen will automatically appear
whenever the MATE has been inactive for the <DELAY> set
point (very much like a screensaver on a computer monitor).
DELAY ROLL
If "None" was selected, the MATE continues to display the
last active screen viewed; if you press the <SUM> soft key on
the MAIN menu when "None" is chosen, the FX SUMMARY
screen appears.
To change the delay time:
In the SETUP/MATE/SUMMARY screen, press the <DELAY> soft
key; this will take you to sum screen delay time.
DELAY ROLL
