Configuration Jumpers

BIOS Bank Select
CMOS Clear
Password Clear
BMC Force Update
Jumper Name
BIOS Bank Select
(J1C3)
CMOS Clear
(J1D1)
®
Intel Server Board S5000PSL
Bank 0
2
Normal
Operation
3
J1C3
Disable
2
Enable
3
J1D1
Protect
2
Clear
3
J1D2
Disable
2
Enable
3
J1E3
Pins
1 - 2
2 - 3
1 - 2
2 - 3
What Happens at System Reset
Bank 0: Boot to an alternate BIOS.
Boot from the standard BIOS. These pins should be
jumpered for normal operation.
Protect CMOS: these pins should be jumpered for normal
operation.
Erase CMOS: If these pins are jumpered for 5 to 10
seconds, the CMOS settings will be cleared on the next
server reset. These pins should not be jumpered for
normal operation.
To clear the CMOS: Power down the server, leaving AC
power connected. Place the jumper on pins 2 - 3 for 5 to
10 seconds. Move the jumper back to pins 1 - 2. Power on
the server.
AF000422
7
