Figure 2. Server Board Connector And Component Locations - Intel S5000PSL - Server Board Motherboard User Manual

F. PCI Express x8 slot 5
G. PCI Express x8 slot 6
H. CMOS battery
I. P12V4 connector
J. RMM connector (connector
®
for Intel Remote
Management Module)
K. Back panel I/O ports (see
Figure 4 on page
L. Diagnostic and Identify
LEDs (see Figure 4 on
page 12)
M. System fan 6 header
N. System fan 5 header
O. Main power connector
P. Auxiliary power signal
connector
6
V. System fan 4 header
W. System fan 3 header
X. IPMB connector
Y. System fan 2 header
Z. System fan 1 header
AA. Processor power connector
12)
BB. USB header
CC. IDE connector
DD. Enclosure management
SATA SGPIO header
(product codes
S5000SLSATA,
S5000SLSATAR,
S5000PSLROMB, and
S5000PSLROMBR)
EE. Intel
header

Figure 2. Server Board Connector and Component Locations

®
Local Control Panel
KK. SATA 2 or SAS 0 (SAS 0 is
available only on product
codes S5000PSLSAS and
S5000PSLSASR)
LL. SATA 3 or SAS 1 (SAS 1 is
available only on product
codes S5000PSLSAS and
S5000PSLSASR)
MM. SATA 4 or SAS 2 (SAS 2 is
available only on product
codes S5000PSLSAS, and
S5000PSLSASR)
NN. SATA 5 or SAS 3 (SAS 3 is
available only on product
codes S5000PSLSAS and
S5000PSLSASR)
OO. USB port
PP. Front control panel header
QQ. SATA_Key: SATA RAID 5
key connector (product
codes S5000PSLSATA,
S5000PSLSATAR,
S5000PSLROMB, and
S5000PSLROMBR only)
RR. SAS_Key: SAS RAID 5 key
connector (product codes
S5000PSLSAS and
S5000PSLSASR only)
SS. Serial B / emergency
management port header
TT. Chassis intrusion header
®
Intel Server Board S5000PSL
