Back Panel Features
The diagram and table show the back panel connectors and LEDs. For information about
the LEDs, see
A
A.
B.
C.
D.
E.
The NIC LEDs at the right and left of each NIC provide the following information.
LED
Left
Right
12
®
"Intel
Light-Guided Diagnostics" on page
C
E
G
B
D
F
Mouse (top), Keyboard (bottom)
Status LED
ID LED
MSB LED (POST LED)
Bit 2 LED (POST LED)
Figure 4. Back Panel Connectors and LEDs
LED State
Off
Solid green
Blinking green
Off
Solid green
Solid amber
H
F.
Bit 1 LED (POST LED)
G.
LSB LED (POST LED)
H.
Serial A (top), Video (bottom)
I.
NIC1 (top), two USB (bottom)
J.
NIC 2 (top), two USB (bottom)
Table 3. NIC LEDs
No network connection is in place
Active network connection is in place
Transmit / receive activity is occurring
10 Mbps connection (if left LED is on or blinking)
100 Mbps connection
1000 Mbps connection
9.
I
J
Description
®
Intel
Server Board S5000PSL
AF000421
