RAID support
Cooling fan support
Management support
4
Table 2. Server Board Features
Feature
•
•
•
•
•
•
•
•
Description
One of the following:
–
Product code S5000PSLSATA an S5000PSLSATAR: Intel
Embedded Server RAID Technology II provides SATA
RAID 0, 1, and 10 with optional RAID 5 support provided by
®
the Intel RAID Activation Key AXXRAKSW5
–
Product code S5000PSLROMB and S5000PSLROMBR:
®
Intel Integrated Server RAID provides four internal and
four external SAS ports. When the optional Intel
KEY AXXRAK18E and RAM are installed, hardware RAID
support is available for RAID 0, 1, 5, 10, and 50. Uses
specially keyed PCI Express slot, add-in card slot 4.
–
Product code S5000PSLSAS and S5000PSLSASR: Intel
Embedded Server RAID Technology II provides SAS/SATA
RAID 0, 1, and 10 with optional RAID 5 support provided by
®
the Intel RAID Activation Key AXXRAKSW5
Two 4-pin processor fan connectors
Four 6-pin front fan connectors
Two 4-pin rear fan connectors
®
Support for the Intel Local Control Panel (optional component
sold separately)
®
Support for Intel Remote Management Module 2 and RMM2
NIC (optional component sold separately)
®
Support for Intel System Management software
®
Intel Light-Guided Diagnostics on field replaceable units
®
Activation
®
Intel Server Board S5000PSL
®
®
