Clearing the Password

If the user or administrator password(s) is lost or forgotten, moving the password clear
jumper into the "clear" position clears both passwords. The password clear jumper must
be restored to its original position before a new password(s) can be set.
1. Power down the system. Leave the AC power cord connected.
2. Open the chassis. See your chassis documentation for instructions on removing the
chassis cover.
3. Locate the Password Clear jumper block at board position J1D2. See
4. Move the jumper from the normal operation position, covering pins 1 and 2, to the
Password Clear position, covering pins 2 and 3, as shown by the diagram.
5. Power up the server and wait 10 seconds.
6. Power down the server.
7. Move the Password Clear jumper back to the original position, covering pins
1 and 2.
8. Close the chassis.
9. Power up the server.
26
PASSWRD CLR
Default
2
Clear
Password
3
J1D2

Figure 7. Password Clear Jumper in Clear Password Position

Figure 7.
AF000423
®
Intel Server Board S5000PSL
